On a Frigidaire that clicks and will not cool, the $40 start relay goes on the meter before the compressor is even mentioned. Frigidaire refrigerator repair for Gallery, Professional, side-by-side, French-door and top-freezer models, plus upright and chest freezers. Licensed and insured, countywide from Spring Valley. Same-day slots for calls before noon; the $90 service call returns as credit on the repair; every job leaves under a 90-day parts and labor warranty.
(619) 330-5105
Most Frigidaire refrigerator repair calls in San Diego come down to three circuits. Defrost: a heater under the evaporator, a defrost thermostat on the coil (OEM 297216600) and the adaptive defrost board that times it. Airflow: the evaporator fan (5303918549) that pushes cold air up the duct and the damper (241600902) that meters it into the fresh-food side. Start: a PTC start relay (a self-resetting thermal switch) and overload (5304491585) on the compressor pins. One failed link means a warm fridge, a sheet of ice, a clicking compressor or an SY EF code. We meter the suspect link before any part is ordered.
Start relay and overload kits ride in the van bins next to defrost thermostats, fan motors, inlet valves and thermistors, because those are the parts a Frigidaire actually needs most. The van leaves 2637 Summitview Ln in Spring Valley and covers Gallery side-by-side and French-door models like the FGSS2635TF and FGHB2868TF, Professional units such as the FPBS2777RF, FFHT top-freezers, and Frigidaire freezers — uprights (FFFU13F2VW) and chests (FFCS0722AW, FFFC09M1RW). Stocked-part jobs are finished on the spot; ordered boards and compressors take one to two business days. Call (619) 330-5105 or book online.
A Frigidaire that got a new compressor when it only needed a start relay is the repair we are hired to undo:
The PTC start relay comes off the pins and is shaken and metered before the compressor windings are even read. A $40 relay plus a short labor line, $180 to $340 all in, is never dressed up as an $850 compressor job.
Phone before noon and you are on that day’s run, seven days a week. If it is the chest freezer in the garage with a quarter of beef inside, say so: a thawing freezer goes ahead of a fridge that is merely running warm.
Who opens your fridge? A company registered at the California Bureau of Household Goods and Services under #C 62399, insured, whose sealed-system work — EPA 608 certified — stays in-house. A Frigidaire compressor swap or refrigerant leak is never handed off.
Day 0, morning: the $90 service call pays for the trip and the meter work. Day 0, an hour later: a written quote with that call credited; decline it and the call is the whole bill. Day 1 through day 90: the installed part and the labor are under warranty, so a repeat of that fault brings us back at no charge.
Frigidaire is an Electrolux brand, so the relay kit, defrost thermostat, fan motor and inlet valve we fit carry Electrolux part numbers (5304491585, 297216600, 5303918549, 242252702), not a cross-reference that fits “most brands”.
A Gallery French-door with through-the-door ice, a Professional all-freezer column, the chest freezer in the garage: the panels come off differently on each, and we have had them all apart.
The classic side-by-side and top-freezer complaint. Most often the evaporator coil behind the freezer back panel is iced solid because defrost quit, so no cold air reaches the fridge; less often a stuck damper (241600902) or a dead evaporator fan.
Click, hum, silence, repeat: the overload trips because the compressor never spun up. On Frigidaire that is usually the PTC start relay. We shake it (a rattle means dead) and meter it before the windings are even read.
A solid sheet on the rear panel is a defrost system that stopped cycling. One of three links is open: the heater, the defrost thermostat (297216600) or the adaptive defrost control (5303918476). We meter all three and replace only the one that failed.
SY EF is the main board saying it cannot see the evaporator fan turning. What we find: a blade locked in ice, a worn motor (5303918549), a chafed harness or a board relay — each a different part, so we test rather than guess.
The 242252702 inlet valve is dual-solenoid: one coil feeds the ice maker, the other the dispenser, and each fails on its own. One side dead is usually a single coil, not an ice maker module. A clogged filter starves both, so the filter is checked first, then each coil is metered.
Melt water leaves the evaporator through a drain trough, down the drain tube, into the pan over the compressor. When the trough freezes, the next defrost backs up under the freezer floor and out to the crispers. We thaw and clear both, then find out why the defrost cycle let it freeze.
The paddle trips a micro switch, which fires the flap solenoid and the auger-motor relay. A click with no ice is a dead solenoid or auger; a dead panel is often the small fuse behind the dispenser that blows with a light bulb. All three are checked before the dispenser board is blamed.
A frost-free FFFU upright shares the defrost heater, thermostat and adaptive board of the refrigerators above, so a caked evaporator gets the same three-link test. Manual-defrost FFCS and FFFC chests have no defrost circuit: a warm chest is relay, capacitor, lid gasket or sealed system.
Frigidaire shows faults as short alphanumeric codes in the temperature windows. The test column is what we check first.
| Code | What Frigidaire means by it | What Spark tests |
|---|---|---|
| SY EF | Evaporator fan error — the main board cannot detect the evaporator fan running. | Blade free of ice, motor 5303918549 spins and draws current, harness, board fan relay. |
| SY CE | Main board and display board not talking. | Harness and connectors at both boards (compressor vibration loosens them), then the boards. |
| SY CF | Communication failure at power-on reset. | 12 VDC on the communication wires at the display (UI) board connector, then the board. |
| OP | Open sensor — thermistor reads infinite resistance. | Thermistor 241608401 and its leads: OL (open line) on the meter means open. The window it shows in names the sensor. |
| SH | Shorted sensor — a thermistor reads below the acceptable range. | Same test: near 0 ohms means shorted. Compared against the tech-sheet chart, within 10%. |
| H1 (H-one, refrigerator display) | High-temperature alarm — the compartment is warmer than its set point. | Door ajar or power cut first; then defrost, evaporator fan, damper and start relay. |
| E1 (freezer) | Freezer temperature sensor error on digital upright freezers. | Freezer thermistor resistance and wiring. |
| E2 (freezer) | Defrost sensor error — defrost cycles become too frequent or stop. | Defrost sensor resistance, heater and thermostat circuit, then the control. |
| HI / LO (H-I, digital freezers) | HI = high-temp alarm; LO = low-temp or control lockout. | HI: gasket, start relay, defrost, sealed system. LO: panel unlock or a 5-minute power-cycle, then the control. |
On a Frigidaire the order starts with the start relay in hand, not the toolbox. Then defrost, airflow and water, each read on the meter so you see the number before you hear a part name.
Fridge unplugged, the PTC relay comes off the compressor pins and gets shaken. A rattle means the pellet inside has shattered; a silent one is metered — a few ohms is good, OL (open line) is not. Only a relay that passes earns the compressor a look.
Freezer back panel off. The heater should read roughly 20 to 35 ohms; OL means open. The 297216600 thermostat has continuity only while cold, so it is tested on the frozen coil. If both pass, we force a defrost from the 5303918476 board and watch for voltage at the heater.
Blade spun by hand for ice or bearing drag, then voltage at the motor with the door switch pressed. Power present and no spin means a new 5303918549 motor. The 241600902 damper is cycled to confirm it opens and reports back.
Overload for continuity, run capacitor for value. Then the windings: common-to-run plus common-to-start must equal start-to-run, and every winding to the shell must read OL. That last reading is the one that starts a compressor conversation.
Each 241608401 thermistor is metered against the tech-sheet chart: roughly 5,000 to 6,000 ohms at room temperature, climbing in ice water; more than 10% off, OL or near zero, and it is replaced. Then supply pressure, both coils of the 242252702 valve and a harvest cycle on the 5303918493 ice maker.
Only the Frigidaire-specific rows are listed; fan motors, gaskets, main boards and ice maker modules cost the same on every brand and sit on our refrigerator repair page. Parts and labor, service call credited — most of these land between $180 and $500.
| Start Relay + Overload Kit 5304491585 (clicking, no cooling) | $180 – $340 |
| Adaptive Defrost Control Board 5303918476 (frost sheet, heater never called) | $260 – $500 |
| Upright Freezer / Freezer-Section Defrost: Heater + Thermostat 297216600 | $200 – $380 |
| Chest Freezer FFCS / FFFC: Start Relay + Run Capacitor | $180 – $320 |
Most Frigidaire refrigerators run a conventional compressor with a PTC start relay rather than the inverter compressors LG and Samsung use, so the start and defrost circuits carry most failures. Access differs by line:
FGSS2635TF side-by-side, FGHB2868TF French-door and other Gallery units. Common jobs: SY EF evaporator fan, defrost heater and thermostat, start relay, inlet valve, OP / SH thermistor codes.
Professional French-door units such as the FPBS2777RF and the all-refrigerator or all-freezer columns, plus the FFHT1835VS and other FFHT / FFTR top-freezers. Common jobs: damper control, adaptive defrost board, condenser fan motor (5303918774), start relay and overload, hinge and gasket.
Frost-free uprights like the FFFU13F2VW and manual-defrost chest freezers such as the FFCS0722AW, FFCS0922AW and FFFC09M1RW. Common jobs: upright defrost heater and thermostat, E1 / E2 / HI codes, start relay and capacitor, lid gasket, control-panel lockouts.
Model numbers we see most on San Diego calls: FGSS2635TF, FGHB2868TF, FPBS2777RF, FFHT1835VS, FFFU13F2VW, FFCS0722AW, FFCS0922AW, FFFC09M1RW — the serial tag inside the fresh-food door covers any other.
Standalone freezer or ice maker only? Freezer repair and ice maker repair cover every brand; Frigidaire ranges and dishwashers live on the Frigidaire appliance repair page.
Every Frigidaire refrigerator repair service visit ends in one of four readings, and each one decides what happens next:
Read dispatch the model from the door tag and whatever the display shows. Morning callers ride that day’s run; an afternoon caller usually hears “first thing tomorrow”; evenings and weekends are on the calendar too. Phone (619) 330-5105, or book online.
The most common outcome on a clicking Frigidaire. The 5304491585 kit comes out of the van bin, the quote is $180 to $340 with the call credited, and the box is cooling again before we pack up.
The heater is fine; the adaptive defrost board is not calling it. The 5303918476 board is ordered to your serial tag and fitted in one to two business days; the reading goes on the quote.
The only reading that turns a visit into compressor talk. You get the repair-versus-replace math on the spot, age and line of the fridge included, before any number is written.
Parts and labor itemized, the service call already credited, nothing ordered until you say yes. Whatever we install carries the 90-day parts and labor warranty described above.
One van base, 2637 Summitview Ln in Spring Valley, sits roughly in the middle of the county. La Mesa and El Cajon are next door, Chula Vista and downtown a short freeway hop, Poway and Escondido the long end of the run. Same-day slots go to the morning callers.
Carlsbad, Encinitas and Del Mar are the far end of that run: call in the morning, and an afternoon call from North County is usually scheduled for the next morning. (619) 330-5105.
The relay story is this page in one line: before a Frigidaire gets an $850 compressor, it gets a $40 relay shaken and metered, and you see the reading. Before noon, call (619) 330-5105 and the slot is today; or book online. The $90 you pay at the door counts toward the repair, and the work is under the 90-day parts and labor warranty.
Take the most common Frigidaire call, the clicker that will not cool. If the start relay rattles and reads OL, the fix is the 5304491585 relay and overload kit: $180 to $340 installed, the $90 service call credited inside that number, done the same visit. If the relay passes and a winding reads to the shell, the honest number is a compressor at $450 to $850 or sealed-system work at $500 to $900, with the repair-or-replace math first. Between those poles sit the adaptive defrost board at $260 to $500 and a defrost thermostat with heater at $200 to $380.
Same symptom either way: the evaporator coil behind the freezer back wall has iced over, so the fresh-food side warms while the freezer stays cold. Which part let it happen depends on age. Older Frigidaires used a mechanical timer that clicked into defrost every six to eight hours for about twenty minutes; current models use the 5303918476 adaptive defrost control, which sets the interval from door openings and compressor run time. We meter the heater and thermostat, then force a defrost from the timer or board and watch for voltage at the heater.
Usually not. The click is the overload cutting power because the compressor never started, and on Frigidaire the cause is most often the PTC start relay. We shake and meter the relay, test the overload and run capacitor, and meter the windings. Only when a winding fails or reads to ground do we talk about a compressor.
Yes. Gallery side-by-side and French-door models with through-the-door ice and water, counter-depth units, and Professional French-door and column refrigerators. The three circuits are shared across the lines; only the access path and board revision change.
Frost-free FFFU uprights and manual-defrost FFCS and FFFC chests. An upright shares the defrost heater, thermostat and board layout of a refrigerator freezer, so it ices up the same way. A chest has no defrost circuit and most often fails at the start relay, run capacitor, lid gasket or sealed system.
Often, yes. A thermistor reading high tells the board the compartment is warmer than it is, so the compressor never cycles off. We meter each 241608401 sensor against the tech-sheet chart; more than 10% off means a new sensor. A dusty condenser, a leaking gasket or a damper stuck open also make a fridge run long.
It is an inexpensive plug-in part, so the temptation is real. The catch: a rattling relay often died because the compressor behind it is pulling locked-rotor amps, and a new relay on a dead compressor lasts a day. We read the windings and the overload first.
Keep the doors shut: a full freezer holds safe temperatures for about 48 hours closed, a half-full one about 24, the fridge side about four hours. Power-cycle once by pulling the plug for five minutes, then leave it alone; repeated unplugging only trips the overload again. If there is water on the floor, shut the small valve on the water line behind the fridge. Have the door-tag model and any display code ready for dispatch.
